BBS-Horizontal Laminar Flow Cabinet Manufacturer,Supplier and Exporter in Uk
Product Code : DS-FHASC-10146
Quick Answer: The BBS-Horizontal Laminar Flow Cabinet has a motorised front window, an LCD display of airflow velocity and UV timer, and a HEPA filter rated 99.999% at 0.3um. It comes in internal widths of 1200mm and 1700mm.
Last updated: October 2026
Key Features
- Motorised front window, max opening 430mm
- LCD shows airflow velocity, UV timer, UV work time and system work time
- Washable polyester pre-filter and HEPA filter, 99.999% at 0.3um
- Transparent 5mm anti-UV toughened glass side and front windows
- Two waterproof sockets and a gas tap
- 304 stainless steel work table
Technical Specifications
| Specification | Value |
|---|---|
| External size (W x D x H) | 1300 x 820 x 2040mm / 1800 x 820 x 2070mm |
| Internal size (W x D x H) | 1200 x 500 x 570mm / 1700 x 500 x 570mm |
| Work surface height | 750mm |
| Airflow velocity | Average 0.3 to 0.5m/s |
| HEPA filter | 99.999% efficiency at 0.3um |
| Noise | Below 60dB |
| Max opening | 430mm |
| LED lamp | 12W x 1 / 16W x 2 |
| UV lamp | 30W x 1, 253.7 nm |
| Power consumption | 400W / 700W |
| Power supply | AC220V ±10%, 50/60Hz; 110V ±10%, 60Hz |
| Gross weight | 254kg / 328kg |
About This Product
The BBS-Horizontal Laminar Flow Cabinet creates a particle-free working area by passing filtered air across the work surface in a unidirectional stream, with enclosed sides under constant positive pressure. A base stand, gas tap, LED lamp, two UV lamps and two waterproof sockets are standard, and the 1800mm model adds a water tap.
Frequently Asked Questions
Q1. What does the LCD of the BBS-Horizontal Laminar Flow Cabinet show?
Airflow velocity, UV timer, UV work time and system work time.
Q2. What sizes are available?
Internal widths of 1200mm and 1700mm, with a 750mm work surface height.
Related: Fume Hoods and Safety Cabinets, Horizontal Laminar Flow Cabinet, BBS-Vertical Laminar Flow Cabinet, Vertical Laminar Flow Cabinet.
For a quotation on the BBS-Horizontal Laminar Flow Cabinet, contact Didac Scientific.
