Electric Height Adjustable Base Stand DID206 Manufacturer,Supplier and Exporter in Uk
Product Code : DS-FHASC-10119
Quick Answer: The Electric Height Adjustable Base Stand DID206 raises and lowers laboratory apparatus over a maximum adjustable route of 400 mm, with a maximum load of 600kg. It moves at 3mm/s with noise below 42dB.
Last updated: October 2026
Key Features
Max adjustable route 400 mm
Max load 600kg (100-600kg optional)
Load speed 3mm/s
Square steel pipe pedestal and aluminium alloy lifting rod
Casters fitted
Easy to install and disassemble
Technical Specifications
Specification
Value
Min. height
480 / 580 / 680 / 730 / 780 mm
Middle height
530 / 680 / 730 / 905 / 980 mm
Max. height
580 / 780 / 980 / 1080 / 1180 mm
Max load
600kg (100-600kg optional)
Load speed
3mm/s
Working frequency
10%, max continuous working time 2 minutes
Noise
Below 42dB
Work temperature
+5 to 40 °C
Pedestal
Square steel pipe, 40 x 40 x 2mm
Lifting rod
Aluminium alloy
Power supply
AC220V ±10%, 50/60Hz; 110V ±10%, 60Hz
Controller consumption
100-200W
About This Product
The Electric Height Adjustable Base Stand DID206 sets the working height of laboratory apparatus placed on it, with five height ranges from 480mm minimum up to 1180mm maximum. It runs at a 10% working frequency, with continuous operation limited to 2 minutes at a time.
Frequently Asked Questions
Q1. How much weight can the Electric Height Adjustable Base Stand DID206 carry? Up to 600kg, with 100-600kg load options.
Q2. How long can it run continuously? Up to 2 minutes at a time, at a 10% working frequency.
