Tractor Attachment Manufacturer,Supplier and Exporter in Uk
Product Code : DS-EE-11571
Quick Answer: The Tractor Attachment is a drive shaft driven implement with 54 curved blades on 9 flanges and a depth of cut of 12-15 cm, for tractors of 50-65 HP.
Last updated: October 2026
Key Features
54 curved blades on 9 flanges
Driven by drive shaft at 540 rpm input
Depth of cut 12-15 cm
For tractors requiring 50-65 HP
Three point linkage CAT-II
Shear bolt shaft safety
Technical Specifications
Specification
Value
Model
R185
Total length
2052 mm
Height
1095 mm
Working width
1907
Required HP
50-65
Three point linkage
CAT-II
Flanges
9, diameter 70-73 mm
Blades
54, curved
Blade to blade distance
422 mm
Input speed
540 rpm
Depth of cut
12-15 cm
Shaft safety
Shear bolt
Weight
407 kg
About This Product
The attachment mounts on a tractor's CAT-II three point linkage and is driven from the drive shaft at an input speed of 540 rpm. Its 54 curved blades on 9 flanges cut to a depth of 12-15 cm, and a shear bolt provides shaft safety. Export supply of the Tractor Attachment can be arranged to laboratories and schools in Mauritius, Panama, Paraguay, Saint Vincent and the Grenadines, and South Korea.
Frequently Asked Questions
Q1. What tractor power does the Tractor Attachment need? It requires 50-65 HP and connects by a CAT-II three point linkage, driven by drive shaft at 540 rpm.
