Digital Oscilloscope Manufacturer,Supplier and Exporter in Uk
Product Code : DS-EE-11481
Quick Answer: The Digital Oscilloscope is a 2 channel digital oscilloscope with a bandwidth of DC ~ 100MHz, a rise time of 3.5ns and 10M memory depth for each channel, shown on a 7" LCD.
Last updated: October 2026
Key Features
Bandwidth DC ~ 100MHz with a 20MHz bandwidth limit
2 channels plus external input
10M memory depth for each channel
7" LCD display
Edge, pulse width, video, runt, rise and fall, timeout, alternate and delay triggers
USB 2.0 host and device ports; saves 20 setups and 24 waveforms
Technical Specifications
Specification
Value
Bandwidth
DC ~ 100MHz
Channels
2 + Ext
Rise time
3.5ns
Bandwidth limit
20MHz
Memory depth
10M per channel
Display
7" LCD
Vertical resolution
8 bit, 1mV~10V/div
DC gain accuracy
±3%
Input impedance
1MΩ ±3%~16pF
Time base range
5ns/div ~ 100s/div
Hold off range
4ns to 10s
About This Product
The Digital Oscilloscope captures and displays signals on two channels, with a time base from 5ns/div to 100s/div and normal, average, peak detect or single acquisition. Trigger types including edge, pulse width, video and delay pick out the event to display, and waveforms can be shown as dots, vectors or with variable or infinite persistence. Setups and waveforms can be saved, and USB ports link it to other devices.
Frequently Asked Questions
Q1. What is the bandwidth of the Digital Oscilloscope? It covers DC ~ 100MHz, with a 20MHz bandwidth limit and a rise time of 3.5ns.
Q2. How many setups and waveforms can the Digital Oscilloscope save? It saves 20 setups and 24 waveforms.
